Welcome to this week’s Tidy Tuesday! Today, we’re delving into the intriguing yet bothersome realm of email spams. You know, those unsolicited messages that flood our inboxes? They go by many names like junk email or spam mail, and they’re sent in bulk. The term “spam” got its name from a Monty Python sketch where the word “Spam” was everywhere, just like these emails. Starting from the early 1990s, these spam messages have been on a steady rise, making up around 90% of all email traffic by 2014.

We’ve got our data from the Tidy Tuesday treasure trove over at GitHub! This dataset, from Vincent Arel-Bundock’s Rdatasets package, was initially gathered at Hewlett-Packard Labs. They later kindly shared it with the UCI Machine Learning Repository.

This treasure trove of information consists of 4601 emaily sorted into spam and non-spam categorie

Setup

import polars as pl
import matplotlib.pyplot as plt
import seaborn as sns
from scipy import stats
import polars.selectors as cs
import numpy as np
from sklearn import preprocessing
from sklearn import decomposition


from lets_plot import *
from lets_plot.mapping import as_discrete

LetsPlot.setup_html()

import plotly.io as pio
import plotly.express as px

pio.templates.default = "presentation"

df = pl.read_csv(
    "https://raw.githubusercontent.com/rfordatascience/tidytuesday/master/data/2023/2023-08-15/spam.csv"
).with_columns(
    [
        pl.col("crl.tot").cast(pl.Int16),
        pl.col("dollar").cast(pl.Float32),
        pl.col("bang").cast(pl.Float32),
        pl.col("money").cast(pl.Float32),
        pl.col("n000").cast(pl.Float32),
        pl.col("make").cast(pl.Float32),
        pl.col("yesno").map_dict({"y": 1, "n": 0}).cast(pl.Int8),
    ]
)

df.sample(5)

Here is the data dictionary:

Variable	Class	Description
crl.tot	double	Total length of uninterrupted sequences of capitals
dollar	double	Occurrences of the dollar sign, as percent of total number of characters
bang	double	Occurrences of ‘!’, as percent of total number of characters
money	double	Occurrences of ‘money’, as percent of total number of characters
n000	double	Occurrences of the string ‘000’, as percent of total number of words
make	double	Occurrences of ‘make’, as a percent of total number of words
yesno	character	Outcome variable, a factor with levels ‘n’ not spam, ‘y’ spam

Looking at the data dictionary, a few intriguing questions arise:

How is the distribution between True and False answers? Are non-spam emails significantly more prevalent?
What are the top words that frequently appear in spam emails?
Can we explore the relative frequency distribution disparities of words linked with spam? What’s the increased likelihood of finding these specific words in a spam email versus a non-spam one?
Is there an overarching correlation within the dataset? Are certain words frequently seen together?
Could we pinpoint the ultimate worst spam email in the dataset?
Would it be feasible to employ principal component analysis to visualize this dataset effectively?

What’s the distribution of True and False answers

(
    df.select(pl.col("yesno"))
    .to_series()
    .value_counts()
    .with_columns((pl.col("counts") / pl.sum("counts")).alias("percent_count"))
)

What are the most frequently used words in spam emails?

fig = (
    df.filter(pl.col("yesno") == 1)
    .select(cs.float())
    .melt()
    .groupby("variable")
    .agg(
        pl.col("value").mean().alias("mean"),
    )
    .sort(by="mean")
    .pipe(
        lambda df: px.bar(
            df,
            x="variable",
            y="mean",
            color="variable",
            width=600,
            height=500,
            labels={
                "mean": "Average % occurrence per total word count",
                "variable": "",
            },
        )
    )
)
fig.update_traces(hovertemplate="<br>Occurence: %{y:.2f}")  #

What are the relative frequency distribution differences of the words associated with spam?

fig = (
    df.select(pl.all().exclude("crl.tot"))
    .groupby("yesno")
    .agg(
        pl.all().mean(),
    )
    .to_pandas()
    .apply(lambda x: x / x.sum(), axis=0)
    .melt(id_vars="yesno")
    .rename(columns={"yesno": "spam"})
    .assign(spam=lambda df: df.spam.map({0: "Not a spam", 1: "Spam"}))
    .assign(percentage=lambda x: ["{:.2%}".format(val) for val in x["value"]])
    .pipe(
        lambda df: px.bar(
            df,
            x="variable",
            y="value",
            color="spam",
            labels={
                "value": "Relative frequency of words compared to class ",
                "variable": "",
            },
            text="percentage",
            width=700,
            height=600,
        )
    )
)

fig.update_layout(
    showlegend=True, uniformtext_minsize=8, uniformtext_mode="hide", hovermode=False
)
fig.update_traces(
    textposition="inside",
)
fig.update_yaxes(tickformat=".0%")

What’s the overall correlation

fig = (
    df.to_pandas()
    .corr()
    .round(2)
    .pipe(
        lambda df: px.imshow(
            df,
            text_auto=True,
            aspect="equal",
            zmin=-1,
            zmax=1,
            color_continuous_scale="RdBu_r",
            # origin='lower',
            width=600,
            height=600,
        )
    )
)
fig.update_xaxes(side="top")

What is the worst spam email?

To identify the most significant culprit within the dataset, we’ll sum up the numerical percentage values and then sort the values accordingly.

(
    df.filter(pl.col("yesno") == 1)
    .with_columns(pl.sum_horizontal(pl.all().exclude("crl.tot", "yesno")))
    .sort(by="sum", descending=True)
    .head()
)

Visualize data with PCA

To enhance our grasp of the data, we can employ Principal Component Analysis (PCA). This technique comes in handy when we’re dealing with multiple independent variables, allowing us to reduce dimensionality and streamline the dataset.

Visualize all the principal components

X = df.select(pl.all().exclude("yesno")).to_pandas()
y = df.select(pl.col("yesno")).to_pandas()

# Before PCA we need to scale and transform our dataset

scaler = preprocessing.PowerTransformer().set_output(transform="pandas")

X = scaler.fit_transform(X)

pca = decomposition.PCA()
components = pca.fit_transform(X)
labels = {
    str(i): f"PC {i+1} ({var:.1f}%)"
    for i, var in enumerate(pca.explained_variance_ratio_ * 100)
}

fig = px.scatter_matrix(
    components,
    opacity=0.2,
    labels=labels,
    dimensions=range(6),
    color=y.squeeze().map({0: "Not a Spam", 1: "Spam"}),
    width=1000,
    height=1000,
)
fig.update_traces(diagonal_visible=False)
fig.show()

Visualize Loadings

For a deeper comprehension of how each characteristic influences our principal components, we can delve into examining the loadings.

pca = decomposition.PCA(n_components=2)
components = pca.fit_transform(X)
loadings = pca.components_.T * np.sqrt(pca.explained_variance_)


fig = px.scatter(
    components,
    x=0,
    y=1,
    color=y.squeeze().map({0: "Not a Spam", 1: "Spam"}),
    labels={
        "0": f"PC1 ({pca.explained_variance_ratio_[0]:.0%})",
        "1": f"PC2 ({pca.explained_variance_ratio_[1]:.0%})",
    },
    template="plotly_dark",
    color_discrete_sequence=[
        "red",
        "green",
    ],
    opacity=0.4,
    width=700,
    height=700,
)
for i, feature in enumerate(X.columns):
    fig.add_annotation(
        ax=0,
        ay=0,
        axref="x",
        ayref="y",
        x=loadings[i, 0],
        y=loadings[i, 1],
        showarrow=True,
        arrowsize=1,
        arrowhead=2,
        xanchor="right",
        yanchor="top",
    )
    fig.add_annotation(
        x=loadings[i, 0],
        y=loadings[i, 1],
        ax=0,
        ay=0,
        font=dict(
            size=20,
            # color='yellow'
        ),
        xanchor="left",
        yanchor="bottom",
        text=feature,
        yshift=5,
    )
fig

Alright folks, our journey into the intriguing realm of spam emails has left us with some valuable insights. It’s clear that words like “bang” and “n000” are key indicators to watch out for. Luckily, modern machine learning models are here to do the hard work on our behalf.

Stay vigilant out there and take care! See you in the next week’s adventure! 👋📧🛡️
